Features

• Premium Italian-made construction delivers exceptional build quality, precision, and durability — perfect for demanding industrial and professional cutting applications.
• 2-way swivel head enables mitre cuts from 0° to 60°, providing outstanding versatility for angled and compound cutting tasks.
• Dual mode operation offers maximum control and flexibility:
  • Trigger switch with manual down feed for quick, small cuts and fine adjustments.
  • Control panel with fully adjustable hydraulic down feed and automatic shut-off at the end of the cut, ideal for larger or precision jobs.
• Heavy-duty dual direction vice ensures strong, secure clamping from multiple angles, enhancing cutting stability and accuracy.
• Integrated recirculating coolant system keeps the blade cool, improves surface finish, and extends blade life.
• Adjustable material stop allows for repeatable, consistent cuts — ideal for production and batch work.
• Equipped with a safety emergency stop switch for immediate machine shutdown, prioritizing operator safety.
• Includes a 12-month warranty for peace of mind and reliable support.
• Supplied complete with a sturdy stand and a high-quality blade, ready for immediate use out of the box.
• Optional variable speed, three-phase model available for enhanced versatility and the ability to cut a broader range of materials with precision.

Specifications

• Motor: 2 hp, Three Phase (415V)
• Blade speed: Two-speed options at 38 or 77 m/min
• Blade size: 27 mm x 0.9 mm x 3200 mm
• Weight: 530 kg

Cutting Capacity

• 90° cutting capacity — Round: 300 mm; Square: 280 mm; Rectangle: 400 x 200 mm
• 45° right cutting capacity — Round: 230 mm; Square: 215 mm; Rectangle: 225 x 140 mm
• 60° right cutting capacity — Round: 140 mm; Square: 140 mm; Rectangle: 140 x 140 mm
• 45° left cutting capacity — Round: 180 mm; Square: 160 mm; Rectangle: 180 x 110 mm
