Features

• Powered by a 7hp 4-stroke OHV engine for efficient performance
• Transistorised ignition system ensures reliable starting
• Cast iron cylinder liner provides consistent performance and enhanced durability
• Rugged full-frame protection for stability and durability
• Higher pressure pump capable of displacing water and spraying with suitable attachments

Specifications

• Bore x Stroke: 68 x 54mm
• Displacement: 196ml
• Compression Ratio: 9:1
• Net Power: 4.2kW / 3600rpm
• Fuel Consumption: ≤395 g/kW-h
• Net Torque: 11N.m / 2500rpm
• Pump Set: 1.5" high lift pump
• Suction Port Diameter: 38mm (1.5")
• Discharge Port Diameter: 1.5" / 1" / 1"
• Suction Head Lift: 7m
• Total Head Lift: 75m
• Discharge Capacity: 12m³/h (200 litres per minute)
• Dimensions (L x W x H): 500 x 395 x 446mm
• Net Weight: 28.5kg
