Features

• Upgrade your existing lever or knob with smart, key-free entry
• Create unique PIN codes for friends and family with the Yale Home app
• Mechanical key override with C4 Keyway for traditional access if needed
• Automatically unlocks as you approach and locks when the door closes
• Compatible with Yale Home module and Apple HomeKit, plus optional upgrade with Yale Connect Plus Hub 2 for remote access and voice assistant integration (Google, Siri, Samsung, Alexa)
• Integrates with Z-Wave Plus and ZigBee home automation systems (modules sold separately)
• Door position sensor alerts whether door is open or closed
• 24/7 lock activity trails to monitor access
• Touchscreen keypad with one-touch locking
• 80 dB internal tamper alarm for enhanced security
• Retrofit to existing 54mm bore holes for quick installation
• Simple installation with just a screwdriver
• Backed by Yale 3 Year Electromechanical and 10 Year Mechanical Warranty

Specifications

• Backset: Adjustable 60-70mm
• Power: 4 x AA Alkaline batteries
• Body / Case Material: Zinc
• Lock Type / Function: Deadlatch Lever
• Door Thickness Range: 35mm to 45mm
• Door Preparation: 25mm latch hole and 54mm lock hole
• Standard Finish: Matt Black and Satin Chrome
• Key Profile (Keyed version): C4
• Operational Temperature Range: -25°C to 60°C
• Operating Humidity: up to 95%
• Approvals: RCM Compliant (EN 61000.6.3 2012 & EN 55032 2016)
• ANSI/BHMA A156.39 Residential Locksets and Latches (Grade A)
• Dimensions (External): Height 92mm, Width 66mm, Length 17mm
• Dimensions (Internal): Height 175mm, Width 75mm, Length 54mm

Includes

• Yale Assure Lever
• Yale Home Module and Door Sense™
• Installation Guide
• Mounting Screws
• Door Template
• 4 x AA Batteries
