Features

• Patented digital deadlocking technology—locks both internal and external handles
• Meets Australian lock standards AS4145.2:2008 (SL8 Security & D8 Durability)
• Certified to BAL-40 Bushfire Level (AS1530.8.1-2007)
• Lock status indicated via built-in LED: Locked (Yellow), Unlocked (Green), Secure (Red)
• 100% key free—no cylinder means no lost keys, and protects against pick and bump break-ins
• Control via Yale Home App, Yale Smart Keypad* or key card
• Auto Unlock feature automatically unlocks as you approach the door
• Tailor user access—grant one-time, scheduled, or permanent access via app
• Door position sensor—alerts whether the door is open or closed
• Compatible with Yale Connect Plus Hub 2* for remote access and integration with Google, Alexa, Samsung & Apple HomeKit
• Yale Unity Nexion Retrofit Kit* available to upgrade Lockwood Nexion Mechanical and Nexion Keyless Entrance Locksets
• Designed for use on entry doors (not suitable for external gate use)
• Low battery warning at 20%
• Durable metal construction with silver powdercoat finish and black nylon

Specifications

• Australian Standards: SL8 (Security), D8 (Durability), BAL-40 (Bushfire Level)
• Compliance: Regulatory Compliance Mark (RCM) for Australia and New Zealand
• IP Rating: IP54
• Operating Temperature: -25°C to 70°C
• Humidity: 0-95%
• Power: 4 x AA Alkaline batteries
• Battery Life: Approx. 12 months
• RFID: 2 x Contactless Key Cards included
• Finish: Silver powdercoat with black nylon
• Backset: Adjustable 60-70mm (70mm latch Y530-222SC sold separately)
• Lock Type: 530 Latch
• Door Thickness: 35mm to 60mm
• Volume Settings: Mute, Low, High
• Low Battery Warning: 20%

Includes

• Yale Unity Entrance Lock
• 2 x Contactless Key Cards
• Mounting screws
• Installation instructions
• Door template
• 4 x AA Alkaline batteries

Compatible Accessories (Sold Separately)

• Yale Connect Plus Hub 2 (Part No: YAR/SWAA/HUB/-I-D)
• Yale Smart Keypad (Part No: 05/301000/BL)
• Yale Unity Nexion Retrofit Kit
• Yale Unity Installation Template
